Low Iron Glass for Greenhouse Applications

Safety Glass Greenhouse With Aluminum Frame

Floor-to-Ceiling Glass Panels – Large glass panels provide wide views and allow natural daylight to enter the greenhouse or enclosed living space. Low-iron glass can be selected where higher visible-light transmission is required.

Custom Thermal and UV-Control Options – Insulated glass, Low-E coatings, laminated glass, or solar-control glass can be specified according to the local climate and required thermal or UV performance. Indoor comfort depends on the complete glass configuration, ventilation, shading, orientation, and frame system.

Multiple Application Options – The aluminum-framed glass structure can be configured as a greenhouse, garden room, lounge, home office, sunroom, or dining area, subject to the project design and local building requirements.

Modern Architectural Design – Slim aluminum framing and large glass panels create a clean, contemporary appearance suitable for gardens, patios, terraces, and approved rooftop installations. Structural loads, drainage, waterproofing, and fixing conditions must be evaluated for each project.

Quantity:
Availability:





Inquire Add to Basket

Product Advantage

Product Uses

Support

FAQ

I. Residential Glass Sunrooms

Core Requirements: Aesthetics, safety, thermal insulation, soundproofing, UV protection.

1. Glass Types and Parameters

Glass Type	Parameters & Characteristics	Applications
Tempered Glass	- Thickness: 5-12mm (single or double-glazed) - Impact resistance: 3-5x stronger than regular glass - Safety: Shatters into granules (meets GB 15763.2)	Walls, roofs (when laminated)
Laminated Glass	- Thickness: 6.38-12.76mm (5mm glass + 0.38mm PVB interlayer) - Penetration resistance: Prevents falling objects and explosions - UV blocking: ≥99%	Roofs (anti-impact)
Insulated Glass	- Thickness: 12-24mm (5mm glass + 12mm air gap + 5mm glass) - U-value: ≤1.8 W/(m²·K) - Sound insulation: Reduces noise by 30-40dB	Walls (thermal & soundproofing)
Low-E Glass	- Thickness: 6-12mm (low-emissivity coating) - UV blocking: ≥70% - Energy efficiency: Heat insulation in summer, warmth retention in winter	Regions with extreme climates

2. Frame Materials

Thermal Break Aluminum:

Insulation bar width: 12-34mm
Wind resistance: ≥2.0 kN/m² (suitable for high-rise buildings)

Steel Structure:

Square steel thickness: ≥2.5mm (hot-dip galvanized for rust prevention)
Load capacity: ≥200 kg/m² (ideal for large-span designs)

3. Auxiliary Systems

Sealant: Weather-resistant silicone (elastic modulus ≥0.4 MPa, lifespan ≥20 years).
Drainage System: Concealed drainage channels with a slope ≥5%.
Shading: Electric shading blinds (80%-100% light blockage) or external louvers.

II. Agricultural Glass Greenhouses

Core Requirements: High light transmission, ventilation, wind/snow resistance, low cost, durability.

1. Glass Types and Parameters

Glass Type	Parameters & Characteristics	Applications
Float Glass	- Thickness: 4-5mm (single-layer) - Light transmission: ≥91% - Cost: Low, but low impact resistance	Sidewalls of standard greenhouses
Tempered Glass	- Thickness: 5-6mm - Wind resistance: ≥1.2 kN/m² - Safety: Shatters into granules	Roofs in hail-prone areas
Diffused Glass	- Thickness: 4-6mm - Feature: Scatters light evenly, prevents crop sunburn	High-light regions (e.g., seedling greenhouses)

2. Frame Materials

Hot-Dip Galvanized Steel:

Pipe diameter: 25-50mm, zinc coating ≥80μm (lifespan 15-20 years).
Snow load resistance: ≥0.5 kN/m² (reinforced in northern regions).

Aluminum Alloy:

Thickness: 1.5-2.5mm, used in Venlo-type greenhouses.

3. Environmental Control Systems

Ventilation:

Roof vents: Opening angle ≥45°, motorized (air exchange rate ≥0.04 m³/s·m²).
Side roll-up films: Manual or motorized (ventilation area ≥30%).

Shading:

External shading nets: 50%-70% light blockage (aluminum or black knitted nets).

Insulation:

Internal thermal screens: PE material, U-value ≤3.0 W/(m²·K) when closed.

III. Key Parameter Comparison

Parameter	Residential Glass Sunroom	Agricultural Glass Greenhouse
Light Transmission	80%-95% (Lower for Low-E glass)	≥91% (Float glass)
Thermal Insulation	U-value ≤1.8 W/(m²·K) (Insulated glass)	U-value ≤5.0 W/(m²·K) (Single glass + screen)
Wind Resistance	≥2.0 kN/m² (High-rise requirements)	≥1.0 kN/m² (Standard regions)
Snow Load Resistance	≥0.75 kN/m²	≥0.5 kN/m² (Reinforced in the north)
Lifespan	20-30 years (High-quality materials)	10-15 years (Galvanized steel + float glass)
Cost	2000-5000 RMB/m² (Premium configurations)	300-800 RMB/m² (Basic models)

IV. Selection Recommendations

Residential Sunrooms:

Prioritize laminated insulated glass (safe roof + insulated walls) with thermal break aluminum frames.
Focus on sealing and shading systems for comfort.

Agricultural Greenhouses:

Recommend 4mm float glass + steel frames (low cost, high light transmission) with roof vents and shading nets.
Use 5mm tempered glass in hail-prone areas; reinforce structures for heavy snow regions.

For further optimization, tailor materials to local climate conditions (e.g., typhoons, snowfall) and usage (planting vs. leisure).

Safety Glass Greenhouse With Aluminum Frame

Product Uses

Residential Garden Cultivation

For home gardeners, the Safety Glass Greenhouse is perfect for growing vegetables, herbs, flowers, and succulents. It extends the growing season, allowing you to start seedlings early in spring and continue harvesting late into fall. The controlled environment protects plants from pests and extreme temperatures, ensuring healthy growth.

Commercial Small-Scale Farming

Small-scale farmers and nursery owners benefit from this commercial greenhouse as it provides a dedicated space for cultivating high-value crops. The durable structure and safe design make it suitable for daily use, while the weather-resistant features ensure consistent growing conditions, improving crop yield and quality.

Educational & Hobbyist Applications

Schools, community centers, and hobbyists can use this residential greenhouse for educational projects or personal enjoyment. It offers a hands-on way to teach students about plant biology, while hobbyists can explore rare or exotic plant species in a protected environment.

Support

Comprehensive Installation Guidance

We provide detailed written instructions and video tutorials to guide you through the assembly process of the Aluminum Frame Greenhouse. If you encounter any issues, our customer support team is available to offer step-by-step assistance.

Reliable After-Sales Support

Our after-sales service covers troubleshooting, technical advice, and solutions for any product-related problems. Whether you have questions about maintenance or need help with parts, our team responds promptly to ensure your Safety Glass Greenhouse operates smoothly.

Accessory Supply & Replacement

We offer a range of compatible accessories, such as shelving, ventilation kits, and temperature gauges, to enhance your greenhouse experience. If any parts get damaged, we provide genuine replacements to maintain the integrity of your durable greenhouse structure.

FAQ

Is the safety glass truly shatter-proof?

Yes, the safety glass used in this greenhouse is designed to resist shattering. If impacted, it breaks into small, rounded pieces that are not sharp, minimizing injury risks.

Can the aluminum frame withstand heavy snow?

Absolutely. The aluminum frame greenhouse is engineered for structural strength, including supporting the weight of moderate to heavy snowfall without bending or collapsing.

Do I need special tools to assemble the greenhouse?

No, the easy-assemble greenhouse comes with all necessary hardware, and standard household tools are sufficient for setup. Most users complete assembly in a few hours.

How often does the greenhouse require maintenance?

As a low-maintenance greenhouse, it only needs occasional cleaning of the glass and frame. No regular painting or sealing is required, thanks to the corrosion-resistant aluminum and durable glass.

Can the greenhouse be moved once assembled?

While the structure is durable, it is designed for permanent or semi-permanent placement. Moving it after assembly may require disassembling and reassembling, which is possible but requires careful handling to avoid damaging the safety glass or aluminum frame.

When selecting glass for a greenhouse, the choice depends on factors like light transmission, insulation, durability, and cost.

1. PVB Laminated glass

Increased safety (shatters safely)

Durability (more resistant to impacts and weather extremes)

High light transmission (like horticultural glass)

Better longevity compared to horticultural glass

2. Insulated Glass

Excellent thermal insulation (reduces heating costs)

Durability (long-lasting structure)

Helps maintain consistent temperature and humidity levels

Good light transmission

Limitations:

More expensive than single-glazed options

Heavier, requiring stronger greenhouse frames

3. Low-E Glass

Energy efficiency (better temperature control)

Reduces UV damage to plants

Maintains optimal growing conditions year-round

Limitations:

Higher cost

Slightly reduced light transmission

4. Low Iron Glasse

Superior light transmission (up to 95%)

Minimal greenish tint (clearer than standard glass)

Improved plant growth due to better sunlight exposure
